This page is made primarily as a reference to ourselves and will ultimately contain a tabulated spec sheet of useful numbers, specs, part lists, etc. Convenient and organized in one sheet so we can set the torque wrench correct when we need to do a quick wheel change or order the right oil filters.

Fluids, Volumes, etc

Fluid Type

Spec/Name

Number and Units

Engine Oil

10W-30, Valvoline VR1

~9.5 US QT oil change

Oil Filter

Fuel

Premium 91 Octane

25 US Gal (94.6 L)

Brake Fluid

2× 51515 / 1515 / ST2 / PH8A

DOT 3/4

3/4-16 THD, 3.66 OD x 5.12 H

Power Steering Fluid

Transmission Fluid Red

Power Steering Filter

Something from a Toyota

Transmission fluid

Smellyass green shit

Roughly a quart?

Fasteners

Fastener

Wheel Lug Nuts

Size

Torque

90 ft-lbs ?

Brake Caliper Mount

M12

75 ft-lbs

M1x Hex Socket

Transmission X-member

Socket/Tool

19 mm Socket

Motor Mount Bottoms

19 mm Socket

Parnhard Bar

62 ft-lbs

19 mm deep socket

Electricals

Circuit/Function

Fuse/Relay/Size

F26 / 10 A

Additional Loc

Front Spare Hot / Wiper Mtr

F21 / 30 A

Front 9CD - 30A

Horn

Apex Lights

DRLs

Fuel Gauge

Switch Panel Power

ECU Standby Power

Rear Hot Spare

F12 / R12 / 20 A

Radiator Fan

F11/ R11 / 30 A

F10 / R10 / 20 A

Front 5CD, 6CD - 5A

Low Beams

F8 / R8 / 30 A

Front 2EF, 3EF, 4EF, 5EF - 5A

F22 / 5 A

Front 1CD, 2CD, 3CD, 4CD - 5A

Flasher Relay

F19 / R17 / 10 A

Front 5-6AB, Rear 4-5AB - 5A

Radio / Cabin Power

F20 / 5 A

Gauge Panel Power

F23 / 15 A

ECU Heated O2 Sensor

F24 / 15 A

F18 / 30 A

Brake Lights

F4 / R4 / 20 A

Rear 1CD, 2CD, 3CD - 5A

Fuel Pump

F25 / 25 A

Rear Spare Switched

F5 / R5 / 30 A

Rear 4EF, 5EF spare

F6 / R6 / 30 A

Wipers Low

F2 / R2 / 30 A

F17 / 30 A

ECU Ignition Switched

F10 / R10 / 30 A

Wipers High

Coolsuit Power

F1 / R1 / 30 A

Spare Front Switched

F16 / R16 / 30 A

F14 / R14 / 30 A

Helmet Air Pump

F13 / R13 / 30 A

Cabin Lights

N/A (Switch Rail)
